Homeowner Reconstruction Floor Plan & Elevation Choices

Last Updated: May 8, 2026

Homeowners eligible for reconstruction are provided with the following pre-approved construction elevation and floor plan options. These options have been developed and approved to meet local, state and federal requirements. Please note that no modifications can be made to these plans except in cases where HOA requirements or site-specific restrictions apply. Applicants approved for mobile home unit (MHU) replacement will work directly with their assigned builder to finalize the selection of a new unit. If you have questions about these plans or the construction process, please contact your Case Manager at (727) 606-3307.

Click any image to open a larger view.

2 Bedroom, 2 Bathroom

Wide (hip roof)

Floor Plan (slab-on-grade)

Architectural floor plan titled “2 Bedroom / 2 Bath Wide Slab – Hip.” The layout depicts a single-story home with a wider floor configuration centered around an open-concept living room and kitchen. The living room occupies the center-right portion of the plan and connects directly to the kitchen and dining area located in the upper-right corner. The primary bedroom suite is positioned in the upper-left portion of the home and includes a private primary bathroom with accessible turning space and fixtures. A secondary bedroom and adjacent bathroom are located along the lower-left side of the plan. Interior hallways and doorways provide circulation between private and common spaces. A small covered front entry porch extends from the lower center exterior wall. The accompanying roof plan illustrates a hip roof layout with central ridges, sloping roof planes, and overhang dimensions. Additional technical information includes sheet number A1.11, project and revision details, scale references, and engineering firm information.

Exterior (slab-on-grade)

Exterior (elevated)

Architectural elevation sheet titled “2 Bedroom / 2 Bath Wide Pier & Beam – Hip.” The page includes front, rear, left, and right exterior elevations of a wider-format single-story home elevated on a pier-and-beam foundation. The front elevation shows a raised covered porch with central stairs leading to the entry door, symmetrical window placement, horizontal siding, and a broad hip roof. Rear and side elevations reveal elevated porch platforms, exposed foundation piers, stair access points, and additional windows distributed across the exterior walls. The wider footprint creates a more horizontally proportioned façade compared to the narrow version. Additional technical information includes sheet number A2.01, project and revision details, scale references, and engineering firm information.

Narrow (hip roof)

Floor Plan (slab-on-grade)

Architectural floor plan titled “2 Bedroom / 2 Bath Narrow Slab – Hip.” The layout shows a single-story narrow home with two bedrooms and two bathrooms arranged along the right side of the structure. The primary bedroom is positioned near the center-right portion of the home and connects to a private primary bathroom with accessible turning space. A secondary bedroom and shared bathroom are located toward the lower-right corner. On the left side of the home, an open-concept living room occupies the lower half of the plan and connects directly to the kitchen and dining area in the upper-left corner. A central corridor and interior doorways provide circulation between the bedrooms, bathrooms, and common living spaces. The plan also includes a covered front entry porch extending from the lower exterior wall. To the right of the floor plan is a matching hip roof plan showing roof ridges, slopes, and overhangs. Additional technical information includes sheet number A1.11, project and revision details, scale references, and engineering firm information.

Exterior (slab-on-grade)

Architectural elevation sheet titled “2 Bedroom / 2 Bath Narrow Slab – Hip.” The document presents front, rear, left, and right exterior views of a narrow single-story home constructed on a slab foundation. The front elevation features a covered front porch with railing, a centered front door, paired front windows, horizontal siding, and a hip roof with moderate overhangs. Rear and side elevations show additional windows, secondary entry doors, and consistent siding and roof detailing around the structure. The slab foundation keeps the structure close to grade level compared to the elevated pier-and-beam version. Additional technical information includes sheet number A2.01, project and revision details, scale references, and engineering firm information.

Exterior (elevated)

Architectural elevation sheet titled “2 Bedroom / 2 Bath Narrow Pier & Beam – Hip.” The page displays front, rear, left, and right exterior elevations of a narrow single-story home elevated on a pier-and-beam foundation. The front elevation shows a centered covered entry porch with stairs leading up to the front door, horizontal lap siding, a hip roof with deep overhangs, and evenly spaced front-facing windows. The rear elevation includes an elevated rear entry with stairs and additional windows. Side elevations show the home’s raised foundation system with visible piers, porch railings, and roof slopes extending over the exterior walls. Additional technical information includes sheet number A2.01, project and revision details, scale references, and engineering firm information.

3 Bedroom, 2 Bathroom

Wide (hip roof)

Floor Plan (slab-on-grade)

Architectural floor plan titled “3 Bedroom / 2 Bath Wide Slab – Hip.” The layout depicts a single-story home with three bedrooms and two bathrooms arranged around a central living space. The primary bedroom suite occupies the upper-left corner and includes a private primary bathroom with accessible maneuvering space. Two secondary bedrooms are located along the right side of the plan and share a nearby hall bathroom. The center of the home contains an open living room connected directly to the kitchen and dining area positioned on the left side. Hallways and interior doors organize circulation between bedrooms, bathrooms, and shared living spaces. A covered entry porch extends from the lower center of the structure. The roof plan on the right side of the sheet illustrates the hip roof configuration with ridges, slopes, and overhangs. Additional technical information includes sheet number A1.11, project and revision details, scale references, and engineering firm information.

Exterior (slab-on-grade)

Exterior (elevated)

Architectural elevation sheet titled “3 Bedroom / 2 Bath Wide Pier & Beam – Hip.” The document displays front, rear, left, and right exterior elevations of a wide single-story home elevated on a pier-and-beam foundation. The front elevation features a raised porch with central stairs, horizontal siding, multiple front windows, and a broad hip roof. Side and rear elevations reveal elevated deck areas, exposed structural piers, stair access, and additional windows distributed across the façade. The wider footprint creates broader front and rear elevations with a more expansive roofline. Additional technical information includes sheet number A2.01, project and revision details, scale references, and engineering firm information.

Narrow (hip roof)

Floor Plan (slab-on-grade)

Architectural floor plan titled “3 Bedroom / 2 Bath Narrow Slab – Hip.” The layout shows a single-story home with three bedrooms and two bathrooms arranged within a narrow rectangular footprint. The primary bedroom suite is located in the lower-right portion of the home and includes a private primary bathroom with accessible clearance space. Two secondary bedrooms are positioned along the upper portion of the plan and share a centrally located bathroom connected by a hallway. The left side of the home contains an open living room and kitchen area with adjacent dining space, creating a combined central gathering area. Interior hallways connect the bedrooms and bathrooms to the common living spaces. A covered front porch projects from the lower-left exterior wall. The sheet also includes a corresponding hip roof plan showing roof ridges, valleys, slopes, and overhangs. Additional technical information includes sheet number A1.11, project and revision details, scale references, and engineering firm information.

Exterior (slab-on-grade)

Architectural elevation sheet titled “3 Bedroom / 2 Bath Narrow Slab – Hip.” The page contains front, rear, left, and right exterior elevations of a narrow single-story home on a slab foundation. The front elevation shows a covered front porch with railing, centered entry door, paired front windows, horizontal siding, and a hip roof. Rear and side elevations illustrate additional windows, side porch elements, and consistent roof overhangs surrounding the structure. The slab foundation keeps the home close to grade while maintaining the same exterior architectural style as the elevated variant. Additional technical information includes sheet number A2.01, project and revision details, scale references, and engineering firm information.

Exterior (elevated)

Architectural elevation sheet titled “3 Bedroom / 2 Bath Narrow Pier & Beam – Hip.” The document displays front, rear, left, and right exterior elevations of a narrow single-story home elevated on a pier-and-beam foundation. The front elevation includes a raised covered porch with stairs leading to the entry, front-facing windows, horizontal siding, and a hip roof with extended overhangs. Rear and side elevations show additional windows, porch access points, stairways, and exposed foundation piers supporting the raised structure. The narrow footprint creates elongated side elevations with continuous siding and roof slopes. Additional technical information includes sheet number A2.01, project and revision details, scale references, and engineering firm information.

4 Bedroom, 2 Bathroom

Wide (hip roof)

Floor Plan (slab-on-grade)

Exterior (slab-on-grade)

Exterior (elevated)

Architectural elevation sheet titled “4 Bedroom / 2 Bath Wide Pier & Beam – Hip.” The document shows front, rear, left, and right exterior elevations of a wide single-story home elevated on a pier-and-beam foundation. The front elevation features a raised covered porch with stairs, multiple windows, horizontal siding, and a broad hip roof spanning the full width of the structure. Rear and side elevations reveal elevated porch platforms, visible foundation piers, stair access, and evenly spaced windows. The wider floor footprint creates expansive front and rear rooflines with balanced exterior proportions. Additional technical information includes sheet number A2.01, project and revision details, scale references, and engineering firm information

Narrow (hip roof)

Floor Plan (slab-on-grade)

Architectural floor plan titled “4 Bedroom / 2 Bath Narrow Slab – Hip.” The layout shows a single-story home with four bedrooms and two bathrooms organized within a narrow rectangular footprint. Three secondary bedrooms are positioned along the upper half of the home and connect to a central hallway and shared bathroom. The primary bedroom suite is located in the lower-right corner and includes a private primary bathroom with accessible turning space. The left side of the home contains an open-concept living room and kitchen area with adjacent dining space, creating a central gathering area for the household. Interior corridors connect all bedrooms and bathrooms to the common living spaces. A covered entry porch projects from the lower center exterior wall. The sheet also includes a hip roof plan illustrating roof ridges, valleys, slopes, and overhangs. Additional technical information includes sheet number A1.11, project and revision details, scale references, and engineering firm information.

Exterior (slab-on-grade)

Exterior (elevated)

Architectural elevation sheet titled “4 Bedroom / 2 Bath Narrow Pier & Beam – Hip.” The document presents front, rear, left, and right exterior elevations of a narrow single-story home elevated on a pier-and-beam foundation. The front elevation includes a raised porch with stairs leading to the entry, multiple front-facing windows, horizontal siding, and a hip roof with wide overhangs. Side and rear elevations show additional windows, elevated side porches, stair access, and exposed structural piers beneath the home. The narrow layout creates elongated side elevations emphasizing the roofline and raised foundation system. Additional technical information includes sheet number A2.01, project and revision details, scale references, and engineering firm information.

Rooflines

Gabled

Architectural rendering of a house with a large front-facing gable centered over the entry porch, integrated into a long horizontal main roofline.

Hip

Architectural rendering depicting the front elevation of a single-story home with a wide hip roof design and a clean, contemporary-traditional appearance.

Shed

Disclaimer: The architectural PDFs linked from this page are not accessible. Pinellas County complies with all federal, state and local laws related to persons with disabilities. To request alternate formats of this information, contact the Office of Human Rights at (727) 464-4062 (V/TDD) or email accommodations@pinellas.gov.
